Data Arrangement
Data Length
Output Example
ECO 3 Byte QS2
1
Notification of mode shifting to STB
1 Byte 1
2
Flag for adjustment of the main unit
1 Byte 0
3
Flag for adjustment-data backup
1 Byte 0
4
"1st PD" data
1 Byte 0
5 "2nd PD" data 1 Byte 0
6 Still picture detection 1 Byte 0
7 Reserved 2 Byte
∗∗
8 Temperature data (TEMP 1) 3 Byte 128 (*
1
)
9 SD main data 1 Byte 0
10 SD sub data 1 Byte 0
11 Operation status induced by SD 1 Byte 0
12 Data from the hour meter 8 Byte 00000259 (*
2
)
13 MASK indication 1 Byte 0
CS 2 Byte 4A
1: Notification of mode
shifting to Standby
0
Entering Standby mode
failed
1
Entering Standby mode
succeeded
2: Adjustment of the
main unit
0 Adjustment completed
1 Adjustment not completed
3: Adjustment-data
backup
0 With backup data
1 No data (default)
6: Still picture detection
0 Normal screen
1 Still picture
4, 5: PD data
0 No PD data
1 Not used
2 POWER
3 SCAN
4 SCN-5V
5 Y-DRV
6 Y-DCDC
7 Y-SUS
8 ADRS
9 X-DRV
A X-DCDC
10-1: SD-Sub (SQ-IC)
0 No SD-Sub data
1 Communication error
2 Drive stop
6 Version mismatching
3 BUSY
B X-SUS
C Not used
D Not used
E Not used
F UNKNOWN
9: SD main data
0 No SD
1 SQ-IC
2 MDU-IIC
3 RST2
4 TEMP
11: Operation status
induced by SD
0 Normal
1 Relay-off completed
2
During warning indication
13: MASK indication
0 MASK-OFF
1 MASK-ON
Note : (*
1
) : The unit scale is centigrade. The data is A/D value from the
thermal sensor.
(*
2
) : "00000259" of "Data from the hour meter" means
2 hours 59 minuts.
10-2: SD-Sub (IIC)
0 No SD-Sub data
1 EEPROM
2 BACKUP
3 DAC
10-3: SD-Sub (TEMP)
0 No SD-Sub data
1 TEMP1
2 Reserved
[QS2] Response format
[QIP] Response format
[QAJ] Response format
Data Arrangement Data Length Output Example
ECO 3 Byte QIP
1 SERIAL 15 Byte - - - - - - - - - - - - - - -
2 HOUR METER 8 Byte 00000000
3 TOTAL HOUR METER 8 Byte 00000000
4 PON COUNTER 8 Byte 00000000
5 TEMP1 acquisition (Temperature value) 5 Byte +23.5(*)
6 TEMP0 acquisition (Temperature value) 5 Byte +28.7(*)
7 MAX-TEMP1 acquisition (Temperature value) 5 Byte +78.3(*)
8 Reserved 4 Byte
∗∗∗∗
CS 2 Byte 94
(*) : Centigrade scale
Data Arrangement Data Length Output Example
ECO 3 Byte QAJ
1 V-SUS adjustment value 3 Byte 128
2 V-OFT adjustment value 3 Byte 128
3 V-RST-P adjustment value 3 Byte 128
4 Reserved 3 Byte
∗∗∗
5 XSB adjustment value 3 Byte 128
6 YSB adjustment value 3 Byte 128
7 YTG adjustment value 3 Byte 128
11 RYW adjustment value 3 Byte 128
12 R-REVICE setting value 1 Byte 0
13 G-REVICE setting value 1 Byte 0
8 YTW adjustment value 3 Byte 128
9 RSW adjustment value 3 Byte 128
10 YTB adjustment value 3 Byte 128
14 B-REVICE setting value 1 Byte 0
CS 2 Byte B7
• For each REVICE setting value, the level set for RRL, RGL, or RBL is transmitted as one character.
