PDP-507CMX
186
1234
1234
C
D
F
A
B
E
[QPW]: Response format
[QPM]: Response format
[QPD]: Response format
Data Arrangement Data Length
Output
Example
ECO 3 Byte QPW
1 Drive sequence 3 Byte 60V
2 Standard/nonstandard 1 Byte S
3 Type of ABL/WB tables 2 Byte T2
4 ABL adjustment value 3 Byte 128
5 R-HIGH adjustment value 3 Byte 256
6 G-HIGH adjustment value 3 Byte 256
7 B-HIGH adjustment value 3 Byte 256
13 Peripheral luminance correction 1 Byte 0
14 Reserved 1 Byte
ā
15 WB interlocked with APL 1 Byte 0
16 Transition of protective operations 1 Byte 0
17 Reserved 2 Byte
āā
8 R-LOW adjustment value 3 Byte 512
9 G-LOW adjustment value 3 Byte 512
10 B-LOW adjustment value 3 Byte 512
11 Gamma setting 1 Byte A
12 Streaking correction 1 Byte 1
CS 2 Byte 37
12, 15: Setting for Items 12 and 15
0 OFF
1ON
13: Peripheral luminance correction
0 OFF
2 ON (interlocked with APL)
3: Type of ABL/WB tables
Tn n: 1 to 4
11: Gamma setting
n0 to F
16: Transition of brightness by protective
operations
0 Upper limit state for brightness
1 Brightness being reduced
2 Lower limit state for brightness
3 Brightness being increased
1: Drive sequence
48V Video 48 Hz
50V Video 50 Hz
60V Video 60 Hz
72V Video 72 Hz
75V Video 75 Hz
60P PC 60 Hz
70P PC 70 Hz
2: Standard / nonstandard
S Standard
N Nonstandard
Data Arrangement Data Length Output Example
ECO 3Byte QPM
1 Pulse meter B 1 8Byte 00000000
2 Pulse meter B 2 8Byte 00000000
3 Pulse meter B 3 8Byte 00000000
4 Pulse meter B 4 8Byte 00000000
5 Pulse meter B 5 8Byte 00000000
CS 2Byte E7
Data Arrangement Data Length Output Example
ECO 3 Byte QPD
1 Latest "1st PD" data 1 Byte A
2 Latest "2nd PD" data 1 Byte 2
3 Data from the hour meter for the latest PD 8 Byte 00010020
4 Second latest "1st PD" data 1 Byte E
5 Second latest "2nd PD" data 1 Byte 9
6 Data from the hour meter for the second latest PD 8 Byte 00008523
7 Third latest "1st PD" data 1 Byte 4
8 Third latest "2nd PD" data 1 Byte 3
9 Data from the hour meter for the third latest PD 8 Byte 00004335
10 Fourth latest "1st PD" data 1 Byte 2
11 Fourth latest "2nd PD" data 1 Byte 0
12 Data from the hour meter for the fourth latest PD 8 Byte 00000945
13 Fifth latest "1st PD" data 1 Byte 4
14 Fifth latest "2nd PD" data 1 Byte 0
15 Data from the hour meter for the fifth latest PD 8 Byte 00000715
16 Sixth latest "1st PD" data 1 Byte A
17 Sixth latest "2nd PD" data 1 Byte 2
18 Data from the hour meter for the sixth latest PD 8 Byte 00000552
19 Seventh latest "1st PD" data 1 Byte A
20 Seventh latest "2nd PD" data 1 Byte 0
21 Data from the hour meter for the seventh latest PD 8 Byte 00000213
22 Eighth latest "1st PD" data 1 Byte D
23 Eighth latest "2nd PD" data 1 Byte 0
24 Data from the hour meter for the eighth latest PD 8 Byte 000001A7
CS 2 Byte 27
1, 2, 4, 5: PD data
0 No PD
1 Not used
2 P-POWER
3 SCAN
4 SCN-5V
5 Y-DRIVE
6 Y-DCDC
7 Y-SUS
8 Address
9 X-DRIVE
A X-DCDC
B X-SUS
C Not used
D Not used
E Not used
F UNKNOWN
