Pioneer XV-E51 - DVD Mechanism Disassembly Steps; Removing DVD Mechanism Components

XV-EV51
97
5 678
56
7
8
C
D
F
A
B
E
1
Remove three screws
5
Remove four screws
6
Remove the DVDM and DVD IF Assys (screws × 6)
(with Shield Plate and Plastic Plate)
Caution : Be careful to installation order of
the Shield Plate and Plastic Plate.
2
Remove a screw
DVD Shield
DVD Mechanism Section
DVD IF Assy
DVDM Assy
Shield Plate and Plastic Plate
DVD Mechanism Section
3
Remove a Fan connector
4
Remove the DVD Shield Section
DVD Mechanism Section
3
Rear View
Top View
Bottom View
1
5
5
5
5
5
5
5
11
2
4
3
5
CN5510
5
×2
×3
