3.2 Product Specifications
Model
S3
Laser type
Galium Aluminum Arsenide (GaAlAs)
diode
Operation mode
Continuous and Pulse
Wavelength(Working)
450±10nm, 650±20nm, 980±10nm
Max Output power
3
±
0.3W, 200
±
20mW, 7
±
0.7W
Wavelength(Indication)
650±20 nm
Max Indication power
＜2mW
Uncertainty for output power
≤±10%
Magnitudes of the cumulative
measurement uncertainty
≤±20%
Expected increase in the measured
quantities
≤±10%
Pulse duration
25μs – 999 ms
Pulse interval
25μs – 999 ms
Transmission system core diameter
200μm,300μm,400μm
NOHD
1.75m
Laser System
Class IV
Fiber
Quartz
Timer
0-3600s
Adapter input parameters
100-240VAC,50/60Hz
Isolation Class
Class I, Type B applied part
Main Unit input parameters
18VDC，5.55A
Battery capacity
3500mAh
Cooling Method
Air cooling Closed loop, liquid filled, heat
pipe thermal transfer system with fan/air
assist.
Weight
≤2KG NW
Dimensions
225

150

150 mm
Date of manufacture
See product nameplate
Validity Period
5 years
Numerical Aperture （NA）
0.22
Divergence Angle
26°
Level of Waterproofing
IPX0

Pioon S3 Specifications
