USER MANUAL Page 8 of 92
Recycle Lithium-Ion
Battery. Do not dispose
with common waste.
1.1.2 Target group
This document is for dentists and office personnel.
1.2 Introduction
The S3 is a portable laser product designed for oral medical laser surgery. This
device is for Professional Use Only and its surgery uses shall only be administered
by or under the supervision of a trained professional. The product is dedicated to
clinicians and patients with a safe and effective treatment experience.
The Medical Diode Laser uses Galium Aluminum Arsenide (GaAlAs) diode lasers as
energy source. The laser energy is delivered to the surgical area by an optical path
transmission system consisting of a flexible fiber connecting the laser source and
hand piece.
The surgical diode laser produces wavelengths at approximately 980 nanometers
(nm) in pulse and continuous mode. The light is both a visible aiming and an
invisible non-ionizing thermal radiation that does not create changes in cellular DNA.
The laser radiation is absorbed by the tissue under management and is converted to
heat. The heat is used for cutting, coagulation, germ reduction and desensitization.
The S3 unit is an air-cooled device consisting of a closed loop, liquid filled, heat pipe
thermal transfer system with fan and air assistance. Heat is transferred to the
system and dissipated across a framework of fins where it is released to the ambient
atmosphere. Please choose a well-ventilated location for equipment installation. The
placement platform requires a hard texture and shall not impede the air flow of the
bottom of the equipment. Keep the device at least 20cm away from the wall or other
equipment to facilitate the operation of the power switch.
For safety, the diode features several ways to stop energy flow to deactivate the
laser. The safety system includes a choice of an emergency shutdown button, a foot
