Figure7 Assembly of the Disposable Fiber Tips
Verify the aiming beam is illuminating evenly by projecting the beam
vertically on a non-reflective working surface or a piece of white paper. The
aiming beam should project a circular light pattern.
If the beam does not protect a circular pattern as portrayed above or the
beam pattern does not illuminate evenly, the single use tip may be
defective.Do not use damaged or defective single use tips.
