10.3.2 Input a.c. power port
Phenomenon
Basic EMC standard
IMMUNITY TEST LEVELS
professional healthcare facility
environment
Electrical fast transients/
bursts
IEC 61000-4-4
±2 kV
100 kHz repetition frequency
Surges Line-to-line
IEC 61000-4-5
±0.5 kV,±1 kV
Surges Line-to-ground
IEC 61000-4-5
±0.5 kV,±1 kV,±2kV
Conducted disturbances
induced by RF fields
IEC 61000-4-6
3 V
0.15 MHz - 80 MHz
6V in ISM bands between 0.15MHz and 80
MHz
80% AM at 1kHz
Voltage dips
IEC 61000-4-11
0% U
T
;0.5 cycle
At0°,45°,90° ,135°,180°,225° ,270°
and 315°
0 % U
T
;1 cycle
and
70 % U
T
;25/30 cycle
Single phase:at 0°
Voltage interruptions
IEC 61000-4-11
0 % U
T
;250/300 cycle
