13.3. Service Parts List
Description
12V
24V
2 Module
4 Module
2 Module
4 Module
Mounting Bracket, Single 2M unit in
19"' Rack
42292S
N/A
42292S
N/A
Mounting Bracket, Two 2M unit in 19"
Rack
42296S
N/A
42296S
N/A
Carry Handle for 2M unit
42506S
N/A
42506S
N/A
Input AC Fuses, 2 per
16499S (15A)
41276S (25A)
16499S (15A)
41276S (25A)
Output DC Fuse
41253S (60A)
40694S (125A)
41284S (30A)
41253S (60A)
Intelligent Power Module (iPM)
42507-B02S
42507-B02S
42508-B02S
42508-B02S
User Interface Module (UIM)
40987-B10S
42276-B20S
40987-B11S
42276-B21S
Remote Battery Temperature Cable,
10 Ft.
40974S
Remote Battery Temperature Cable,
30 Ft.
40976S
Remote Battery Voltage Cable, 10 Ft.
40977S
Remote Battery Voltage Cable, 30 Ft.
40978S
Input Varistor, across input AAR
terminals
31309S
Output Varistor, across output AAR
terminals
41283S
Mounting Brackets, 4M in 19" Rack,
2M or 4M Back or Bottom
42193S
iPM, Blank, Cover Plate, 1 per
41838S
