ATR401 - User manual 37
20   Remote Setpoint
Enables remote setpoint. The control setpoint is sent by another device
and is received by second analogue input.
Parameter    must be selected as  or 
   Disabled (Default)
 Enabled
 Enables remote setpoint by serial input only on ATR401-ABC-T
(see par. 7.3)
21  Command Action Type
Regulation type for command output.
 Heating (N.O.) (Default)
 Cooling (N.C.)
 Lock command above SPV. Example: command output is not
activated when reaching setpoint, even with P.I.D. value other
than 0.
22  Command Hysteresis
Hysteresis in ON / OFF or dead band in P.I.D.
0.0-999.9 digit
5
(tenth of degree if temperature), Default: 0.
23  Command Rearmament
Type of reset for contact of command output (always automatic in P.I.D.
functioning).
 Automatic Reset (Default)
 Manual Reset by keyboard.
 Manual reset stored. (keeps relay status also after an eventual
power failure)
24  Command State Error
Contact state for command output in case of error.
  Open contact (Default)
  Closed contact
25   Command Led
De nes led C1 state corresponding to relevant contact.
  ON with open contact
  ON with closed contact (Default)
