38 ATR401 - User manual
26   Command Delay
Command delay (only in ON / OFF functioning). (In case of valves it works
also in P.I.D. and represents delay between opening and closure of two
contacts).
-600…+600 seconds (tenth of second in case of servo valve).
Negative: delay when turning o .
Positive: delay when turning on.
Default: 0.
27   Command Setpoint Protection
Allows/prevents changes to command setpoint value by keyboard.
 Modi cation allowed (Default)
  Protected
28  Tune
Autotuning type selection.
   Disabled (Default)
 Automatic (P.I.D. parameters calculation at each activation and /
or each change)
 Manual (launch by keyboards or by digital input)
 Once (P.I.D. parameters calculation only at  rst start)
29  Setpoint Deviation Tune
Selects deviation from command setpoint as threshold used by
autotuning to calculate P.I.D. parameters.
0…5000 digit
5
(tenth of degree if temperature), Default: 10.0.
30   Proportional Band
Process inertia in units (example: °C if temperature).
0 ON / OFF if also  is equal to 0 (Default).
1…9999 digit
5
(tenth of degree if temperature).
31    Integral Time
Process inertia in seconds.
0.0…999.9 seconds. 0 integral disabled, Default: 0.0
5
The display of the decimal point depends on the setting of parameter . and    or
 and  
