ATR401 - User manual 47
77      Proportional Band Multiplier
Proportional band for cooling action is given by parameter 30 multiplied
for this parameter
1.00…5.00
Default: 1.00
78  Overlap / Dead Band
Dead band combination for heating / cooling P.I.D.
-20.0…50.0%.
Negative: Dead band.
Positive: overlap.
Default: 0.0.
79  Cooling Cycle Time
Cycle Time for Cooling output
1…300 seconds
Default: 10
80   Conversion Filter
ADC Filter: Number of sensor readings to calculate mean that de nes
process value.
NB: When readings increase, control loop speed slows down
   Disabled
   2 Samples Mean (Mean with 2 samples)
  3 Samples Mean
   4 Samples Mean
  5 Samples Mean
   6 Samples Mean
   7 Samples Mean
   8 Samples Mean
  9 Samples Mean
   10 Samples Mean
      11 Samples Mean
    12 Samples Mean
    13 Samples Mean
   14 Samples Mean
  15 Samples Mean
