INTRODUCTION
BREECH SENSOR
(BS) INDICATOR
FIG-1
The BS indicator
A
displays the various states of the breech sensor.
BS enabled and a ball is detected
The marker can be red up to the selected rate of re.
BS enabled and NO ball is detected
The marker cannot be red.
BS disabled
The marker can be red up to the rate of re set by the BS
OFF ROF parameter (see page 27).
BS enabled in training mode
Training mode is enabled and simulates ring up to the
selected rate of re.
BS disabled in training mode
Training mode is enabled and simulates ring up to the rate of
re set by the BS OFF ROF parameter.
BS fault detected
Breech Sensor is temporarily disabled. The marker can be
red up to a rate of re that is 2bps lower than that set by the
BS OFF ROF parameter.
BS fault has been cleared and a ball is detected
The marker can be red up to the selected rate of re.
BS fault has been cleared and NO ball is detected
The marker cannot be red.
