PLANET ECLIPSE LV1.6 - LV1.6 Bolt Assembly

FIG-1
Bolt pin o-ring
#014 NBR70
Bolt pin
Plunger
Bolt insert
Bolt tip
Rammer cap o-ring
#013 NBR70
Rammer cap
Rammer bumper
Plunger spring
Bolt body
Insert o-ring
#012 NBR70
Middle o-ring
#011NBR70
Front o-ring
#010 NBR70
Rammer shaft
Rear o-ring
#010 NBR70
Rammer bumper
#010 NBR70
Bolt o-rings
14x2 NBR70
51
TECHNICAL INFORMATION
LV1.6 BOLT ASSEMBLY
