RESET
FACTORY RESET
Follow these steps in order to reset the LV1.6 to the way that it left
the factory.
FIG-1
Navigate to the PRESET menu and load the FACTORY settings.
See page 26.
FIG-2
Using the 1/8 hex key
A
turn the LPR adjuster screw
B
1/2 turn
counter-clockwise from it’s fully screwed-in position.
FIG-3
Using the 1/8 hex key
A
turn the velocity adjuster screw
B
5 turns
clockwise from it’s fully screwed-out position.
FIG-4
The rear SFR
A
should be set to the 12 o'clock position and the front
SFR
B
should also be set to the 12 o'clock position.
WARNING!
Do not turn the adjuster screw in too far. This will prevent the marker from ring.
WARNING
