INSTALLING THE BATTERY
The LV1.6 uses 1 x 9V alkaline battery (IEC 6LR61 / ANSI 1604A)
situated in the frame.
Switch the marker o before you begin.
FIG-1
Using a hex key
A
remove the grip screws
B
(both sides of the grip
frame) then pull and remove the grips.
You can access the battery by just releasing the right side of the grips.
FIG-2
To remove the battery
C
use the pocket at the base of the battery
D
to
leverage the battery out.
Install a fresh battery and replace the grips as per FIG-1.
WARNING!
DO NOT use poor quality batteries.
