PLANET ECLIPSE LV1.6 - Tournament Lock Button

FIG-1
FIG-2
5/64
B
C
A
+
-
17
INTRODUCTION
THE TOURNAMENT
LOCK BUTTON
FIG-1
To access the tournament lock button use a hex key
A
to remove the
grip screws
B
(both sides of the grip frame) then pull and remove the
grips.
You can access the tournament lock button by just releasing the right
side of the rubber grips.
FIG-2
Push the tournament lock button
C
to toggle the tournament lock
state – which will be displayed on the LCD. See page 13 for more.
Replace the rubber grips as per FIG-1.
WARNING!
Always ensure the marker is made safe before changing the tournament lock
state to avoid accidentally ring the marker.
WARNING
