PLANET ECLIPSE LV1.6 - Low Rise Clamping Feed Tube Assembly

FIG-1
G
C
E
F
I
A
B
D
H
55
TECHNICAL INFORMATION
LOW RISE CLAMPING FEED TUBE ASSEMBLY
FIG-1
A
Clamping feed nut o-ring
#004 NBR70
B
Clamping feed nut
C
Short clamping feed screw
10-32 UNF x 1/2”
D
Feed tube
E
Feed insert
F
Machined clamping feed screw
G
Feed swivel o-ring
#006 NBR70
H
Feed swivel
I
Feed lever
