19
FIG-1
A
Ensure that a barrel blocking device is still tted for safety.
B
Switch the marker OFF.
C
De-gas the marker.
Push in and hold the POPS button and pull the POPS bonnet
away from the POPS body.
D
Remove the pre-set air system.
Rotate the air system counter-clockwise from the POPS body.
E
Loosen the clamping feed-neck.
Open the feed-neck lever away from the feed-neck.
Rotate the feed-neck lever screw counter-clockwise.
F
Remove the loader.
If the feed-neck is too tight, loosen the clamping feed-neck screw.
G
Remove the barrel from the marker body.
Rotate the barrel counter-clockwise to remove.
H
Remove the barrel tip from the barrel insert.
Rotate the barrel tip clockwise to remove.
1
IMPORTANT! Extra precaution to avoid injury.
2
IMPORTANT! To switch OFF/ON, see page 08.
3
IMPORTANT! Always de-gas before unloading.
4
IMPORTANT! Always remove air system before unloading.
5
IMPORTANT! Always remove any paintballs from the breech of the
marker once the loader has been removed.
6
IMPORTANT! The barrel tip is reverse threaded so unscrew it
CLOCKWISE.
INTRODUCTION
UNLOADING THE LV1.6
WARNING!
Always make sure the marker is O with a barrel blocking device installed and
that no paintballs are in the breech or loader before unloading.
Compressed air and nitrogen systems can be extremely dangerous if handled
or used incorrectly.
NEVER leave the marker gassed up when unloading.
NEVER point your marker in the direction of other people when not on the eld.
Remove any paintballs from the breech before storing your marker.
