Planet HPOE-2400G User Manual

 PLANET Smart Discovery utility automatically finds PLANET devices on the network
 PLANET NMS system and CloudViewer for deployment management
 SNMP v1, v2c and v3 for system status monitoring
 SNMP trap for alarm notification of events
 System event log/remote syslog
 Scheduled System Power Rebooting
 Network Diagnostic
− ICMPv6/ICMPv4 Remote Ping
− Trace Route
 Hardware
 19-inch rack mountable; 1U height
 Reset button for resetting to default setting and system reboot
 LED indicators for PoE ready and PoE activity
 LED indicators for power alert and fan alert
 FCC Part 15 Class A, CE
1.4 Product Specifications
Product
POE-1200G
HPOE-1200G
POE-2400G
HPOE-2400G
Hardware
Hardware Version 6
Interface
“Data” Input Ports
12 x RJ45
12 x RJ45
24 x RJ45
24 x RJ45
“Data + Power” Output
Ports
12 x RJ45 12 x RJ45 24 x RJ45 24 x RJ45
Management Port
1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate 10/100/1000Mbps
Power Requirements
100-240V AC,
50/60 Hz, 4A
100-240V AC,
50/60 Hz, 8A
100-240V AC,
50/60 Hz, 8A
100-240V AC,
50/60 Hz, 12A
Power Consumption
251 watts/
856 BTU
382 watts/
1303 BTU
514 watts/
1753 BTU
719 watts/
2453 BTU
Ventilation
Smart Fan x 2
Dimensions (W x D x H)
440 x 300 x 44mm
Weight
3.6kg 3.9kg 4kg 4.3kg
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
LED
System: SYS PWR x 1 (Green)
PoE Failure x 1 (Red)
Fan 1 Failure x 1 (Red)
Fan 2 Failure x 1 (Red)
Per PoE Port: PoE-in-use x 1 (Amber)
Management port x 1: LNK/ACT (
Green
)
Network Cable
10BASE-T: 4-pair UTP Cat5 up to 100m (328ft)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft)
1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
