2.1.3 Injector Rear Panel
The rear panel of the PoE+ Managed Injector Hub indicates an AC inlet power socket, which accepts input
power from 100 to 240V AC, 50/60Hz. Figures 2-1-6 & 2-1-7 & 2-1-8 & 2-1-9 show the rear panel of the PoE+
Managed Injector Hub.
Figure 2-1-6: POE-1200G Rear Panel
Figure 2-1-7: HPOE-1200G Rear Panel
Figure 2-1-8: POE-2400G Rear Panel
Figure 2-1-9: HPOE-2400G Rear Panel
The PoE+ Managed Injector Hub is a power-required device, meaning
Injector Hub will not work till it is powered. If your networks should be active all the time
please consider using UPS (Uninterrupted Power Supply) for your device. It will prevent
you from network data loss or network downtime.
In some areas, installing a surge suppression device may also help to protect your device
from being damaged by unregulated surge or current to the PoE+ Managed Injector Hub
the power adapter.
