Planet HPOE-2400G User Manual

4.5.7 Diagnostics
The page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press
“Ping”, ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon
reception of a reply. The Page refreshes automatically until responses to all packets are received, or until a
timeout occurs. The Ping web screen shown in Figure 4-5-8.
Figure 4-5-8: Ping Web Page
Diagnostics
Object Description
Interface
Select an interface of the PoE+ Managed Injector Hub.
Target Host
The destination IP Address or domain.
Number of Packets
Set the number of packets that will be transmitted; the
maximum is 100.
Ping
The time of ping.
Table 4-5-7: Descriptions of the Ping Objects Screen
