The page includes the following fields:
Object
Description
• New Name
The ID of the user.
Maximum length: 18 characters.
• Password
Enter the user’s new password here.
Maximum length: 18 characters.
• Confirm Password
Please enter the user’s new password here again to confirm.
Button
: Click to apply changes.
Please remember the newly set-up “user name” and “password”; in case the
user name and
password are forgotten, please re-install the PLANET Modbus Gateway Utility.
3.5.3.2 Import Network Topology
: This function provides the import topology in PLANET Modbus Gateway Utility.
Step 1: Click the shortcut icon for the “import Network Topology” and enter search screen of administrator PC.
Step 2: Choose a “.BEF” document to be imported.
3.5.3.3 Export Network Topology
: This function provides the export topology in PLANET Modbus Gateway Utility and saved as “.BEF” document. For
further review, please use the “Import Network Topology” function.
Step 1: Click the shortcut icon for the “Export Network Topology” and enter screen of administrator PC.
Step 2: Choose the saving route and fill in the document name, and click Save to save as “.BEF” document.
3.5.3.4 Zoom In
: This function provides the zoom in topology in PLANET Modbus Gateway Utility.
3.5.3.5 Zoom Out
: This function provides the zoom out topology in PLANET Modbus Gateway Utility.
