User’s Manual of WGR-500-4P and WGR-500-4PV
4.5.4 PoE Status
This page allows user to see the usage of individual PoE Port as shown in Figure 4-48.
Figure 4-48: PoE Status
Object Description
Port Number Displays per port status.
Watt Displays per port PoE usage.
Indicates the AF PoE operation mode of that port.
Indicates the AT PoE operation mode of that port.
Refresh Press this button to refresh the current Web page.
Auto Refresh
Check this box to refresh the page automatically. Automatic refresh occurs
every 3 seconds.
