User’s Manual of WGR-500-4P and WGR-500-4PV
3.2 Web Management
The industrial wall-mount Gigabit router offers management features that allow users to manage the industrial
wall-mount Gigabit router from anywhere on the network through a standard browser such as Microsoft Internet
Explorer. After you set up your IP address for the industrial wall-mount Gigabit router, you can access the
industrial wall-mount Gigabit router’s Web interface applications directly in your Web browser by entering the IP
address of the industrial wall-mount Gigabit router.
The following shows how to start up the Web Management of the Industrial wall-mount Gigabit router. Note the
Industrial Router is configured through an Ethernet connection. Please make sure the manager PC must be set to
the same IP subnet address. For example, the default IP address of the Industrial Router is 192.168.1.1, then the
manager PC should be set to 192.168.1.x (where x is a number between 1 and 254) and the default subnet mask
is 255.255.255.0 as shown in Figure 3-1.
Figure 3-1: Web Management
You can then use your Web browser to list and manage the industrial wall-mount Gigabit router configuration
parameters from one central location; the Web Management requires Microsoft Internet Explorer 8.0 or later.
1. Use Internet Explorer 8.0 or above Web browser and enter IP address http://192.168.1.1 to access the Web
interface.
2. When the following dialog box appears, please enter “admin” in both the default user name and password
fields. The login screen shown in Figure 3-2 appears.
Default IP Address: 192.168.1.1
Default Username: admin
Default Password: admin
