Planmeca ProX User Manual

PREPARATIONS FOR THE EXPOSURE
10 Planmeca ProX
User’s Manual
When attaching the film to the holder make sure that the
film is in the same direction as the rectangular collimator.
NOTE The exposure values must be selected according to
the cone used in the exposure, refer to the section 15
“EXPOSURE VALUES” on page 34.
7.2.3 RINN film holder
Attach the RINN compatible rectangular collimator to the
long cone. The film holder can be attached to the
collimator.
Film and collimator sides
in the same direction
RINN compatible
rectangular collimator
RINN film holder

Planmeca ProX Specifications

General

Type	Intraoral X-ray
Tube current	7 mA
Imaging Technology	Digital
Focal spot	0.4 mm
X-ray generator	High-frequency
Power Requirements	100–240 V AC, 50/60 Hz
Tube voltage	60-70 kV
