This device supplies power to the power socket on the rear of the main sterilizer using the dedicated
power connection line for STERLINK mini, and provides protection against electric shock by
connecting the grounding conductor to ground. The power of the pump unit is supplied through the
power connection line fixed on the rear of the main sterilizer. In order to use the device, the supplied
pipe must be plugged into the one-touch fitting on both the main sterilizer and pump module.
This STERLINK system can be used with a sticker type label-printer as an accessory which is for
user convenience in managing the history of sterilization cycle information. The label printer and
the main sterilizer can be connected using a USB cable to the USB B port on the rear side of main
sterilizer. The USB B port is only used when using label printer. The label printer receives power
using the separately provided printer power adapter. For the detailed information about the report,
please refer to the Chapter 7 featuring “Reports and Data”.
Fig. 3.5 Label Printer & Label Sticker Roll for the STERLINK mini Sterilization System
Fig. 3.6 Dedicated cart for STERLINK mini sterilization system
Moreover, the mobility of the sterilizer can be improved by means of a dedicated cart. The main
sterilizer can be placed on the cart, and the pump module can be hidden inside the cart. The label-
