Plustek PS188 - Save Setup Dialog Box (for FTP Button Settings)

MacAction Help30
All rights are reserved.
Port
Enter the number of Port connections for FTP transfers, e.g. 21.
Remote Directory
S
pecify a directory on the remote host to
determine where the scanned
documents or images are saved
.
Anonymous connection
Tick this check box to enable Anonymous connection. Otherwise, you have to
enter the
Username
and the
Password
for the FTP connection.
Passive Mode
Tick this check box to enable Passive Mode. This option may be necessary to
pass firewalls with connection restrictions.
Delete file after transfer complete
Tick this check box to delete the scan images saved in the specified
Saving
Folder after the upload transfer is completed.
2.7.2
Save Setup dialog box (for FTP Button Settings)
Within the Button Configuration window click the
FTP
icon on the left pane and
then click
in the right pane, which opens this dialog box.
The items and parameters available in the window are explained as follows:
Saving Folder
The scanned documents or images are saved to the folder displayed here.
To select or modify the saving folder, click
to open a dialog box where you
may browse your disk drives to select a desired saving folder. This newly
added saving folder will be added to the drop-down menu. Next time when you
want to use this folder again, you may simply click to select it from this drop-
down menu.
File Name
