9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
3.133
COOLING HOSE - COLD SIDE ROUTING / RETENTION CONTINUED
Cooling hoses are secured in 2 locations with panduit straps
q
and 1 location with a hose clamp
w
as shown.
COOLING HOSE - COLD SIDE ROUTING / RETENTION CONTINUED
Cooling hose is secured in 3 locations
q
as shown.
ENGINE / COOLING / EXHAUST
