10.94
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
ELECTRIC START HARNESS ROUTING
NOTICE
Images for reference only.
1. The electric start harness connector
q
should be connected to the chassis harness in location shown below.
2. The electric start harness should route down the right footrest tube and secured with a panduit
w
in location
shown.
3. Connect the start solenoid connector
e
to the start solenoid.
4. The electric start harness / battery bullet connector wire should be routed along the battery box bracket and
secured in the edge clip / panduit in the location shown
r
. The edge clip / panduit should retaining the battery
tender fuse.
BATTERY / ELECTRICAL
