SKS RAIL BEAM DETAIL
q
Rail Tip Screw
u
Bumper Screw
w
Limiter Strap Shaft
i
Bogie Wheel Mounts
Mount to outside of each rail.
Left Rail: Forward Holes
Right Rail: Rear Holes
e
Bumper Screw
o
Rear Torque Arm Mount
r
Front Shock Shaft
a
Rail Brace Shaft / Screws
t
Front Torque Arm Mount
s
Adjuster Block Rivets
y
Bogie Wheel Mounts
Mount to outside of each rail.
Left Rail: Forward Holes
Right Rail: Rear Holes
