Polaris 850 PRO-RMK 155 2020 - QuickDrive Low Inertia Drive System

6
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
6.23
QUICKDRIVE LOW INERTIA DRIVE SYSTEM
QUICKDRIVE ASSEMBLY VIEW
q
Backer Plate
t
Washers
w
Bearings
y
Screw (M10 x 1.25 x 45)
44 ft-lbs (60 Nm) Use new fasteners during assembly
e
Snap Rings
u
QuickDrive Belt
r
Upper Sprocket
i
Lower Sprocket
FINAL DRIVE / BRAKE SYSTEMS
