10.98
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
ELECTRIC START / BATTERY BULLET CONNECTORS
1. The electric start harness battery power bullet connector should be connected to the female bullet connector as
shown
q
.
2. The electric start harness battery bullet connector wire should be routed along the battery box bracket and secured
in the edge clip / panduit in the location shown
w
.
3. Complete routing by connecting the electric start harness battery bullet connector to the female bullet connector as
shown
e
.
BATTERY / ELECTRICAL
