9.2
BRAKES
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS SPECIAL TOOLS
FRONT BRAKE SYSTEM
Item Standard Service Limit
Front Brake Pad Thickness .300 ± .007" (7.62 ± .178 mm) .180" (4.6 mm)
Front Brake Disc Thickness .188" (4.76 mm) .170" (4.32 mm)
Front Brake Disc Runout - .010" (.254mm)
REAR BRAKE SYSTEM
Item Standard Service Limit
Rear Brake Pad Thickness .298 ± .007" (7.57 ± .178 mm) .180" (4.6 mm)
Rear Brake Disc Thickness .188" (4.76 mm) .170" (4.32 mm)
Rear Brake Disc Runout - .010" (.254 mm)
Item
Torque
ft. lbs.
Torque
Nm
Front Caliper Mounting Bolts 30 40
Rear Caliper Mounting Bolts 18 24
Brake Line Flare 12-15 16-20
Brake Line Banjo Bolts
(Caliper Attachment)
15 20
Brake Line Banjo Bolt
(Master Cylinder Attachment)
15 20
Front Brake Disc to Hub Bolts 28 38
Rear Brake Disc to Hub Bolts 28 38
Brake Switch 12-15 16-20
Master Cylinder to Frame 17 23
Brake Pedal Mounting
Bracket to Frame
15 23
Part Number Tool Description
2870975 Mity Vacâ„¢ Pressure Test Tool
