9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual

3.101

VALVE COVER INSTALLATION

1. Install spark plugs

and torque to specification.

TORQUE

Spark Plugs:

9 ft-lbs (12 Nm)

2. Prepare valve cover sealing surfaces by cleaning

thoroughly to remove all residue.

3. Inspect the valve cover seal

and replace if

necessary.

4. Replace the isolators

around each T40 bolt.

5. Install the four valve cover shoulder bolts

and

isolators using a T40 driver.

6. Torque valve cover bolts in sequence to specification.

TORQUE

Valve Cover Bolts:

7 ft-lbs (10 Nm)

ENGINE / COOLING SYSTEM
