Polaris RZR PRO XP 2021 - Driven Clutch Removal; Driven Clutch Service

6
9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
6.31
4. Install the clutch cover
i
and clutch cover bolts
o
.
Hand tighten bolts.
5. Torque cover bolts in a cross pattern evenly to
specification.
TORQUE
Drive Clutch Cover Bolts:
15 ft-lb (21 Nm)
6. Install drive clutch assembly and drive clutch bolt
a
.
Torque bolt to specification.
TORQUE
Drive Clutch Bolt:
140 ft-lbs (190 Nm)
DRIVEN CLUTCH SERVICE
DRIVEN CLUTCH REMOVAL
1. Loosen the clamp
q
retaining PVT inlet duct to the
outer clutch cover.
PVT SYSTEM
