5.24
9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
9. Loosen two hose clamps and remove rubber hose
u
from the fuel tank.
10.Remove any remaining fasteners retaining the fuel
tank to the frame.
11. Lift the rear of the fuel tank up first. Carefully pull the
fuel tank out of the vehicle.
FUEL TANK INSTALLATION
1. Reverse the removal procedure for fuel tank
installation.
TORQUE
Fuel Tank Fasteners:
15 ft-lbs (20 Nm)
TORQUE
Body Panel Fasteners:
7 ft-lbs (10 Nm)
TORQUE
Seat Base Frame Fasteners:
15 ft-lbs (20 Nm)
TORQUE
Shift Knob Fastener:
35 in-lbs (4 Nm)
TORQUE
Shift Knob Fastener:
13 ft-lb (18 Nm)
TORQUE
Battery Cable Fasteners:
60 in-lbs (7 Nm)
EFI / FUEL SYSTEM
