9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
9.55
RZR PRO XP FRONT SHOCK VALVING
COMPRESSION REBOUND CLICKER ASSEMBLY
1.500 x 0.120 1.300 x 0.015 0.700 x 0.010
0.700 x 0.012 1.200 x 0.010 CLICKER PISTON
0.900 x 0.008 1.100 x 0.012 1.100 x 0.025
1.100 x 0.010 1.000 x 0.012 0.700 x 0.006
1.200 x 0.012 0.900 x 0.012 1.000 x 0.025
1.300 x 0.008 0.800 x 0.010 0.625 x 0.065
1.450 x 0.012 0.750 x 0.065
1.500 x 0.012
1.200 x 0.008
1.550 x 0.010
1.200 x 0.008
1.550 x 0.010
Piston Bleed Orifice: none
RZR PRO XP 4 FRONT SHOCK VALVING
COMPRESSION REBOUND CLICKER ASSEMBLY
1.500 x 0.120 1.300 x 0.015 0.700 x 0.010
0.700 x 0.012 1.200 x 0.012 CLICKER PISTON
0.900 x 0.008 1.100 x 0.012 1.100 x 0.025
1.100 x 0.010 1.000 x 0.012 0.700 x 0.006
1.200 x 0.012 0.900 x 0.012 1.000 x 0.025
1.300 x 0.012 0.800 x 0.010 0.625 x 0.065
1.450 x 0.012 0.750 x 0.065
1.500 x 0.012
1.200 x 0.008
1.550 x 0.010
1.550 x 0.012
Piston Bleed Orifice: none
STEERING / SUSPENSION
