9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
9.57
RZR PRO XP REAR SHOCK VALVING
COMPRESSION REBOUND CLICKER ASSEMBLY
1.650 x 0.010 1.550 x 0.012 0.700 x 0.010
1.650 x 0.010 1.450 x 0.010 CLICKER PISTON
1.550 x 0.008 1.300 x 0.010 1.000 x 0.015
1.500 x 0.008 1.200 x 0.010 1.000 x 0.015
1.100 x 0.008 1.200 x 0.010 0.900 x 0.015
1.450 x 0.010 1.100 x 0.012 0.600 x 0.015
1.300 x 0.010 1.000 x 0.010 0.600 x 0.015
1.200 x 0.008 0.900 x 0.012
1.100 x 0.008
0.750 x 0.065 (round side
towards shim)
0.800 x 0.012
0.800 x 0.012
1.500 x 0.125
No Piston Bleed Orifice
RZR PRO XP 4 REAR SHOCK VALVING
COMPRESSION REBOUND CLICKER ASSEMBLY
1.550 x 0.012 1.550 x 0.010 0.700 x 0.010
1.500 x 0.008 1.450 x 0.010 CLICKER PISTON
1.100 x 0.008 1.300 x 0.010 1.000 x 0.015
1.450 x 0.010 1.200 x 0.010 1.000 x 0.015
1.300 x 0.010 1.100 x 0.010 0.900 x 0.015
1.200 x 0.010 1.000 x 0.010 0.600 x 0.015
1.100 x 0.010 0.900 x 0.012 0.600 x 0.015
0.800 x 0.012
0.750 x 0.065 (round side
towards shim)
1.500 x 0.125
No Piston Bleed Orifice
