10
9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
10.15
7. Repeat procedure until clean fluid appears in bleeder
hose and all air has been purged. Add fluid as
necessary to maintain level in reservoir.
IMPORTANT
Do not allow the brake fluid level in the reservoir to drop
below the MIN line to prevent air from entering the
master cylinder.
NOTICE
There is a rib within the reservoir that separates fluid
between front and rear brake systems. It may appear
that there is fluid in the reservoir even if the rear half of
the reservoir is empty.
8. Tighten bleeder screw securely and remove bleeder
hose. Torque bleeder screw to specification.
TORQUE
Bleeder Screw:
47 in-lbs (5 N·m)
9. Repeat steps 5 - 8 for the remaining calipers.
10. Add brake fluid to MAX level on reservoir.
Master Cylinder Fluid Level
Between MIN and MAX lines on reservoir.
11. Install master cylinder reservoir cover.
12. Field test machine at low speed before putting into
service. Check for proper braking action and pedal
reserve. With pedal firmly applied, pedal reserve
should be no less than 1/2"(1.3 cm).
13. Check brake system for fluid leaks.
BRAKE SYSTEM
