Pum p Induction Notes:
A Apply continuous bead of marine grade silicone to a mating surfaces of the hull, scoop, front and side.....
edges of ride plate, and front and rear sections of the inlet grate. PN 8560054. Cavitation may occur
if silicone is not continuously applied. Allow 24 hours to cure before operating watercraft.
B Apply marine grade silicone to O--ring......
C 8ft.l bs. (11N m) Appl y Lo ctitet 242 to threads......
A
A
A
B
C
C
Pump Housing
O--ring
Intake Scoop
Intake Grate
Ride Plate
A
Final Drive / Propulsion
5.7
2002 Pump Induction -- Freedom / Vir age Ser ies
