Polaroid Joshua Vision User Manual

4 - 24
LOCKING
TAB
BASE BLOCK
ASSEMBLY
PC BOARD AND
LENS MOUNTING
PLATE
j. Using tweezers, remove the Release Button Spring (Figure 4-31) from the Release Button
Latch.
k. Lift out the Release Button Latch from the Base Block Assembly.
Figure 4-29. Removal of Ambient/IR Lens, Solenoid Retainer/Contacts, Front Lens and Solenoid #2
Figure 4-30. Removal of PC Board and Lens Mounting Plate Assembly
FRONT LENS
SOLENOID CONTACT
RETAINER
CONTACTS
AMBIENT/IR
LENS
LENS MOUNTING
PLATE
PC BOARD
SOLENOID #2
