Poly CCX 600 Business Media Phones Hardware
The following figure displays the hardware features on Poly CCX 600 business media phones. The table
lists each feature numbered in the figure.
Figure 1: Poly CCX 600 phone hardware features
Poly CCX 600 Phone Hardware Feature Descriptions
REFERENCE
NUMBER
FEATURE FEATURE DESCRIPTION
1 Reversible tab
Secures the handset in the cradle when you position your
phone stand at a high angle. To secure the handset, remove
the tab, reverse it so the protrusion points up, and reinsert
it. Position the handset so the protrusion on the tab fits into
the slot on the handset.
2 Touchscreen
Enables you to select items and navigate menus on the
touch-sensitive screen.
3 Camera Port
Enables you to attach an optional Poly EagleEye Mini USB
camera.
4
Message
waiting
indicator
Flashes red to indicate you have an incoming call or new
messages.
5
Application
Command
Displays when the phone is powered on and the service is
available. Icon may vary.
6, 7 Volume keys
Adjusts the volume of the handset, headset, speaker, and
ringer.
8 USB port(s)
One USB-A port and one USB-C port.
Enables you to attach a USB flash drive or USB headset.
You can connect an EagleEye Mini USB camera to the USB-A
port.
9
Headset
indicator
Displays when the phone is powered on. The icon glows
green or blue when a headset is connected and activated.
10
Speakerphone
indicator
Displays when the phone is powered on. The icon glows
green when activated.
11 Speaker Provides ringer and speakerphone audio output.
12 Mute Key Mute or unmute the microphone during an active call.
