Statistics and Diagnostics
11 - 3
Call Statistics
Diagnostic Screen Description
Call Status
(system only)
Displays call type, data speed, and number dialed for
the current call. You can highlight the spheres on this
screen to see the number dialed, the relevant status
code, and details of any errors.
In ISDN calls, this screen also displays connection
status for each channel. Selecting a channel call
progress indicator displays its ISDN number.
Call Statistics Displays call speed, audio and video protocols,
annexes, and error count for the call in progress.
View Call Statistics during a call by pressing
Help on the remote control.
Call Statistics (1)
• Call speed (transmit and receive)
• Video protocol, annexes, and format in use
(transmit and receive; the video protocol is shown
in green if the system is currently using error
concealment
• Audio protocol in use (transmit and receive)
• Number of packets lost and percentage packet
loss (transmit and receive) in IP calls
• Encryption type, key exchange algorithm type,
and key exchange check code (if the encryption
option is enabled and the call is encrypted)
• Far site details and call type
Call Statistics (2)
• Audio and video data rates specified (transmit and
receive)
• Video data rate and frame rate in use (transmit
and receive)
• Video packet loss and jitter in IP calls
• Audio packet loss and jitter in IP calls
• Far site details and call type
Content Statistics
The Content Statistics screen shows statistics for
content shared during a call, including transmit
statistics for People+Content IP.
Call Summary The Call Summary screen provides details about the
calls placed by the system, including:
• Duration of the last call
• Total number of calls placed and received
• Number, total time, and percentage of IP calls
• Number, total time, and percentage of ISDN calls
