C1
0.0
Compressor Delay (Cd)
This menu item allows you to adjust the minimum amount of time (in seconds) the Compressor should be OFF
before it cycles back ON.
To change the compressor delay, rotate the Select/Set Knob until the desired value is displayed.
Cd
20
Flow Rate Calibration (Fc)
NOTE: Your Chiller’s flow rate is calibrated at the factory at the nominal flow value for the installed pump.
Further adjustment is not necessary.
This menu item allows you to adjust the flow rate display to match that of a known standard.
1. Press and hold
the Units/Menu Button until HL appears on the display.
2. Press and release the Units/Menu Button until Cd appears on the display.
3. Press and hold
the Units/Menu Button.
4. While holding the Units/Menu Button, press and release the Select/Set Knob.
5. When CAL appears on the Temperature Readout, release the Units/Menu Button.
6. Rotate the Select/Set Knob until the desired offset is displayed. Press the Select/Set Knob or simply allow
the display to time out to accept the displayed value.
Fc
0.0
Coolant Density (dS)
This menu item is for factory use only and should not be changed.
dS
8.35
Specific Heat (Sh)
This menu item is for factory use only and should not be changed.
Sh
1.00
Current Control (CC)
This optional menu item allows you to adjust the temperature set point using a 4-20 mA analog signal. To
change the displayed setting, rotate the Select/Set Knob until the desired selection is displayed (YES = enabled;
NO = disabled).
CC
NO
110-279 28
