5-3
5 Technical Specifications
Figure 5.2: Dimensions of the measurement range [A] with stand, spacer ring and tip-tilt
unit (Unless otherwise specified, all dimensions are in mm.)
5.3 TMS-I-500 Sensor Head
5.3.1 General Data
Ambient Conditions
INFORMATION
The instrument can make measurements in the given temperature range.
However, the specifications with regards to the measurement uncertainty can
only be warranted in a temperature range of 20 ±3 °C.
Housing
Calibration
Noise emission
Illumination Module (L
ED
)
Operating temperature: +10…+33 °C (50…91.4 °F)
Storage temperature: –10…+65 °C (14…149 °F)
Air humidity: max. 80%, non-condensing
Dimensions (w x d):
350x678mm
2
(standard setup)
Weight: approx. 25 kg (standard setup)
Recommended calibration
interval: 2 years
Noise level: ≤ 70 dB(A)
Wavelength: 525 nm
Max. power output: 14 mW
