Power Electronics SD700 Series Hardware And Installation Manual

SD700 SERIES
POWER ELECTRONICS
38
POWER CONNECTION
It is recommended to route in separately cable racks, trays or ducts, the following cable types:
 Single-wire signal or data cables with V< 60V
 Single wire cable with 60V<V< 230V
 Input power cables with low level of interferences 230V<V<1000V
 Output motor power cables and Dynamic brake DC cables with high level of interferences
230V<V<1000V.
 Medium voltage cables with V<1000V
The power cables must have sufficient current rating to prevent important wiring overheating and voltage
drops. The installer must consider the cable cross-section, cable type, routing method and the ambient
conditions to select the appropriate cable. It is only permitted the use of cooper or aluminium cables. The
maximum cable section and the available holes per phase could be found in the “Power connection
terminals” section.
6.3.1. Recommended Cable Section for 400VAC
FRAME
CODE
I(A)
Rated
Power (kW)
at400VAC
Recommended
Cable Section
per Phase
Recommended
Cable Section
for Earth Wire
AWG /
kcmil
mm²
AWG /
kcmil
mm²
1
SD70006 5X
6
2,2
12 – 10
2,5 – 4
12 – 10
2,5 – 4
SD70009 5X
9
4
12 – 10
2,5 – 4
12 – 10
2,5 – 4
SD70012 5X
12
5,5
10 – 8
4 – 6
10 – 8
4 – 6
SD70018 5X
18
7,5
10 – 8
4 – 6
10 – 8
4 – 6
SD70024 5X
24
11
10 – 8
4 – 6
10 – 8
4 – 6
2
SD70032 5X
32
15
6 – 4
6 – 10
6 – 4
6 – 10
SD70038 5X
38
18,5
6 – 4
10 – 16
6 – 4
10 – 16
SD70048 5X
48
22
3 – 1
16 – 25
3 – 1
16 – 25
3
SD70060 5X
60
30
3 – 1
16 – 35
3 – 1
16 – 35
SD70075 5X
75
37
1 – 1/0
25 – 50
1 – 1/0
25 – 50
SD70090 5X
90
45
1/0 – 3/0
25 – 50
1/0 – 3/0
25 – 50
SD70115 5X
115
55
2/0 – 4/0
50 – 95
2/0 – 4/0
50 – 95
4
SD70150 5X
150
75
3/0 – 300
70 – 120
3/0 – 300
70 – 120
SD70170 5X
170
90
3/0 – 300
95 – 150
3/0 – 300
95 – 150
5
SD70210 5X
210
110
300 – 500
120 – 240
300 – 500
120 – 240
SD70250 5X
250
132
350 – 500
185 – 240
350 – 500
185 – 240
SD70275 5X
275
150
2 x 300
2 x 150
2 x 300
2 x 150
6
SD70330 5X
330
160
2 x 350
2 x 185
2 x 350
2 x 185
SD70370 5X
370
200
2 x 500
2 x 240
2 x 500
2 x 240
SD70460 5X
460
250
2 x 500
2 x 240
2 x 500
2 x 240
7
SD70580 5X
580
315
3 x 500
2 x 240
3 x 500
2 x 240
SD70650 5X
650
355
3 x 500
3 x 240
3 x 500
3 x 240
SD70720 5X
720
400
4 x 500
3 x 240
4 x 500
3 x 240
8
SD70840 5X
840
450
4 x 500
4 x 240
4 x 500
4 x 240
SD70925 5X
925
500
4 x 500
4 x 240
4 x 500
4 x 240
SD70990 5X
990
560
6 x 500
6 x 240
6 x 500
6 x 240
9
SD71150 5X
1150
630
6 x 500
6 x 240
6 x 500
6 x 240
SD71260 5X
1260
710
6 x 500
6 x 240
6 x 500
6 x 240
SD71440 5X
1440
800
7 x 500
7 x 240
7 x 500
7 x 240
10
SD71580 5X
1580
900
8 x 500
8 x 240
8 x 500
8 x 240
SD71800 5X
1800
1000
8 x 500
8 x 240
8 x 500
8 x 240
11
SD72200 5X
2200
1200
9 x 500
9 x 240
9 x 500
9 x 240
Note: Cable must be suitable for a permanent Tª >75ºC. Use 600V cables for up to 500Vac rated voltage.
For 525Vac and 690Vac phase to phase rated equipment use 1kV cables. However, this is only a
recommendation. You must follow the local regulation.
