COMMISSIONING
73
Verify that the display is turned on and set the drive control parameters
(Follow the instruction delivered in Software and Programming manual).
Check line voltages displayed.
Start the drive without motor using the display’s keyboard pushbutton
“START”.
Check that the fans rotate smoothly and there is any obstacle reducing the
cooling capacity.
Connect the motor and check its rotation direction.
Check that the drive follows the references of speed, current, etc.
Connect input power supply.
