SD750
POWER ELECTRONICS
14
CONFIGURATION TABLE & STANDARD RATINGS
CONFIGURATION TABLE &
STANDARD RATINGS
Configuration table
To consult the configuration table of SD750 drives manufactured by Power Electronics, please refer to
the latest brochure (visit http://www.power-electronics.com).
Standard ratings
Voltages in the standard ratings shown in the following tables are the three-phase input voltages for the
drive.
The number of pulses depend on the number of transformer secondaries at drive input.
6 pulses: Transformer with a single secondary.
2
