TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
380 - 480Vac, 500 - 690Vac and 690Vac, 3 phases (±10%)
INPUT RECTIFIER TECHNOLOGY
Diode-Diode Frames 1 and 2 / Thyristor-Diode Frames 3 to 11
DISPLACEMENT POWER FACTOR
(DPF = cos Φ )
POWER FACTOR
(PF= I
1
/I
rms
· cos Φ)
> 2s (depending on the load inertia)
Second environment (Industrial): (C3 Standard)
First environment (Domestic): C2 (Optional). C1 consult Power Electronics
Optional IT filter
Constant torque: 150% during 60s at 50ºC
Variable torque: 120% during 60s at 40ºC
EFFICIENCY (At full load)
VECTOR CONTROL
Open Loop. PWM speed control (OLSP) / torque (OLTQ), AVC: speed control (OLSP) /
torque (OLTQ)
Close Loop (Encoder): PWM speed control (CLSP)/torque (CLTQ), AVC: speed control
(CLSP)/torque (CLTQ)
PMSM Without sensor
External B150 Dynamic Brake (Integrated in Frames 1 and 2)
OPERATION AMBIENT
TEMPERATURE
Minimum: -20°C Maximum: +50°C (Constant torque)
Minimum: -20°C Maximum: +40°C (Variable torque)
Minimum: -40°C Maximum: +70°C
> 1000m, 1% P
N
(kW) per 100m; 4000m maximum
IP20, IP54, GL Marine Series (IP44/IP54)
Amplitude: ± 1mm (2Hz-13.2Hz), ± 0.075mm (13.2Hz-57Hz)
Acceleration: 6.86m/s² (13.2Hz-57Hz), 9.8m/s² (57Hz-150Hz)
Rotor Locked, Overload (thermal model), Output Current Limit, Phase Current
Imbalance, Phase Voltage Imbalance, Motor Overtemperature (PT100 signal), Speed
Limit, Torque Limit
IGBT Overload, Input Loss, Low Input Voltage, High Input Voltage, Bus Voltage Limit,
Bus Low Voltage, High Supply Frequency, Low Supply Frequency, IGBT Temperature,
High Temperature in the Radiator, Power Supply Fault, Temperature Sensors for Drive
Thermal Control, Ground Fault, Software and Hardware Fault, Loss of Analog Input
Signals (Loss of Speed Reference), Safe Stop / Stop Emergency
[1]: Other configuration, consult Power Electronics.
[2]: For operation frequencies higher than 100Hz consult Power Electronics.
[3]: Depending on the nominal power, input voltage and according to the recommendations of installation of Power Electronics.. In case of configuring
the AI3 en PT100 mode, any of the two analogic outputs must be configured in 10 mA mode.
[4]: SC: Shielded cable, USC: Unshielded Cable. For other distances consult Power Electronics.
