Hardware technical specifications
8 cables, half and full duplex, RJ45 ending
Ethernet 10Base-T, Ethernet 100Base-TX
Data Interconnection Protocol
Modbus TCP/IP, Ethernet/IP
Supports DHCP auto-addressing
10Mbps, 100Mbps, auto-negociation 10 / 100
IEEE 802.3, IEEE 802.3u (only for 100Base-TX)
2 cables, optically insulated, half duplex, RS485 differential mode
'1' logical = +5V differential
'0' logical = -5V differential
'1' logical = +5V differential
'0' logical = -5V differential
± 50VDC regarding to the earth
Programmable inputs via Modbus
2 programmable analogue inputs (0 – 10V, ±10V, 0 – 20mA, 4 – 20mA)
Programmable outputs via Modbus
2 programmable analogue outputs (0 – 10V, ±10V, 0 – 20mA, 4 – 20mA)
Max. number of SD750 in network
Connector: USB 1.1 and 2.0 type
B.
Controller FTDI chip
Model FT232BM
For the correct operation of the USB connection, it is necessary to install the
proper drivers. To this, simply access to the information of the appropiate
model in:
http://www.ftdichip.com/Drivers/VCP.htm
From this site you can download the required files and complete their correct
installation.
Note: For the installation of the driver in the Host of the SD750 USB, it is only necessary to indicate the driver at
the time of the installation. The USB device will be detected by the operating systems XP or later versions. In case
of operating systems before W98 / Me, execute a search of new Hardware in the device administrator and complete
the installation by indicating the drivers when the computer requires them.
